Inconel 600 / 601 / 625 / 718 Forged Fittings Supplier

  • Home
  • Inconel 600 / 601 / 625 / 718 Forged Fittings Supplier

Products

Dedicated Customer Teams & Agile Services

Our worldwide presence ensures the timeliness, cost efficiency compliance adherence required to ensure your production timelines are met.

Inconel 601 Screwed Fittings, ASTM B564 Inconel Alloy 718 Socket weld Fittings, Inconel 600 Forged Fittings, Inconel 2.4816 Forged Fittings, UNS N06601 Forged Fittings, ANSI B16.11 Alloy 625 Forged Fittings, Nickel Alloy 601 Forged Fittings, Inconel 625 Threaded Fittings Manufacturer in Pune India.

Om Steel  is a renowned distributor and supplier of Inconel Alloy Forged Fittings, which reflects the amounts of chromium (22 %) and nickel (5 %) in the alloy. We offer this product in different grades such as Inconel 600 Forged Fittings, Inconel 601 Forged Fittings, Inconel 625 Forged Fittings, Inconel 718 Forged Fittings, and so on. The main advantage of our Inconel Forged Threaded Fittings is the combination of properties given by both the austenitic and Ferritic structure (austenitic – Ferritic). These Inconel Forged Socket Weld Fittings is being used for pulp and paper digesters, liquor tanks and paper machines. Whilst our Inconel Forged Threaded Tee Fittings are being considered resistant to stress corrosion cracking, they are not as resistant to this form of attack as Ferritic stainless steels. These Inconel Forged Socket Weld Tee Fittings has lower thermal expansion and higher thermal conductivity than austenitic stainless steels. Our Inconel Forged Threaded Elbow Fittings is often used for Nuclear Sector, Dished Ends, Oilfield Fabrications, Filters, and so on. These Inconel Forged Socket Weld Elbow Fittings can be used successfully as an alternative to 300 series austenitic stainless steels in almost all applications where higher mechanical strength / lower weight are required. Mechanical properties of these Inconel Forged Threaded Cross Fittings vary by means of product form and temper. Alloying elements in Inconel Forged Socket Weld Cross Fittings also have an effect on the eutectoid temperature of the steel.

Inconel 600 / 601 / 625 / 718 Forged Fittings Supplier

Alloy 625 Screwed Coupling Exporter, Inconel 2.4856 Forged Pipe Nipple, Inconel 601 Forged Union, ASME SB564 Inconel 718 Threaded Tee, Alloy N07718 Forged Elbow, Inconel Socket weld Cross Supplier in Pune India.

Specification of Inconel 600 / 601 / 625 / 718 Forged Fittings

Specifications: ASTM B564 / ASME SB564

Dimensions: ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799

Size: 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)

Type: Socketweld Fittings, Screwed-Threaded Fittings

Class: 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS

Grade: Inconel 600, 601, 625, 718 Forged Fittings

Type: Pipe Caps, Union, Tee, Cross, Bull Plug, Boss, Hex Head Bushing, Hex Head Plug, Square Head Plug, Round Head Plug, Hex Nipple, Street Elbow, Full Coupling, Half Coupling, Reducing Coupling, Swage Nipple, Pipe Nipple, Adapter.

Available Types of Inconel 600 / 601 / 625 / 718 Forged Fittings

Equivalent Grades of Inconel 600 / 601 / 625 / 718 Forged Fittings

STANDARDWERKSTOFF NR.UNSJISBSGOSTAFNOREN
Inconel 6002.4816N06600NCF 600NA 13МНЖМц 28-2,5-1,5NC15FE11MNiCr15Fe
Inconel 6012.4851N06601NCF 601NA 49XH60BTNC23FeANiCr23Fe
Inconel 6252.4856N06625NCF 625NA 21ХН75МБТЮN600DNB4MNiCr22Mo9Nb
Inconel 7182.4668N07718

Chemical Composition of Inconel 600 / 601 / 625 / 718 Forged Fittings

GradeCMnSiSCuFeNiCr
Inconel 6000.15 max1.00 max0.50 max0.015max0.50 max6.00 – 10.0072.00 min14.00 – 17.00
Inconel 6010.10 max1.0 max0.5 max0.015 max1.0 maxBalance58.0 – 63.021.0 – 25.0
Inconel 6250.10 max0.50 max0.50 max0.015 max5.0 max58.0 min20.0 – 23.0
Inconel 7180.08 max0.35 max0.35 max0.015 max0.30 max50.00 – 55.0017.00 – 21.00

Inconel 600 / 601 / 625 / 718 Forged Fittings Mechanical Properties

ElementDensityMelting PointTensile StrengthYield Strength (0.2%Offset)Elongation
Inconel 6008.47 g/cm31413 °C (2580 °F)Psi – 95,000 , MPa – 655Psi – 45,000 , MPa – 31040 %
Inconel 6018.1 g/cm31411 °C (2571 °F)Psi – 80,000 , MPa – 550Psi – 30,000 , MPa – 20530 %
Inconel 6258.4 g/cm31350 °C (2460 °F)Psi – 1,35,000 , MPa – 930Psi – 75,000 , MPa – 51742.5 %
Inconel 7188.2 g/cm31350 °C (2460 °F)Psi – 1,35,000 , MPa – 930Psi – 75,000 , MPa – 48245 %
