Monel 400 / K500 Pipes & Tubes Supplier
Products
Dedicated Customer Teams & Agile Services
Our worldwide presence ensures the timeliness, cost efficiency compliance adherence required to ensure your production timelines are met.
Monel Alloy K500 Seamless Tubing, ASTM B165 Alloy 400 Tube, Monel 400 Tube, Monel Alloy K500 Tubes, Monel 2.4360 Pipes, Monel Alloy 400 Tubes, Monel Steel K500 Pipes, Monel 400 Tubes Manufacturer in Pune India.
Om Steel is one of the prime manufacturers of Monel Alloy 400 / K500 Pipes and Tubes that are being sourced by using high quality of raw material and makes sure to provide durability of highest quality of industry standard products. Monel Alloy 400 Seamless Pipes offers an inferior cost option to commercially untainted Nickel because of the Copper content. However, it preserves very parallel properties to Nickel 200 / Nickel 201 Pipes. Monel Alloy K500 Seamless Pipes are almost nonmagnetic, even at relatively low temperatures Also referred as UNS N04400, these Monel 400 Pipes are engaged for heat exchanger piping, process vessels, and storage tanks of gasoline and potable water in the marine sector. And also referred as UNS N05500, these Monel K500 Pipes has an extremely superior dimensional stability. Meanwhile, these pipes and tubes can further be customized in terms of sizes and thicknesses as per specific requirements given by our esteemed clients. We offer the same at market leading prices.
Monel Alloy UNS N05500 Seamlees Tubing, Alloy K500 Seamless Pipes, Monel 400 Welded Tubes, ASME SB725 Monel Alloy 400 Pipes/Tubes Exporter, Monel Alloy K500 Pipes, Alloy 400 Tubing, Monel K500 Tubes Supplier in Pune India.
Specification of Monel Alloy 400, K500 Pipes/Tubes
Pipe/Tube Specifications: ASTM B725,B165, B725/ ASME SB165, SB725
Dimensions:ASTM, ASME
Pipe Outside Diameter: 6.00 mm OD up to 914.4 mm OD, Sizes up to 24″ NB available Ex-stock, OD Size Steel Tubes available Ex-stock
Tube Outside Diameter: 1/8″ OD TO 2″OD 3MM OD TO 38 MM OD
Range:1/2” OD up to 5” OD, customs diameters also available
Type: Seamless / ERW / Welded / Capillary Tubes
Form: Round Tube, Square Tube, Rectangular Tube
Length: Single Random, Double Random & Required Length
End: Plain End, Beveled End, Treaded
End Protection: Plastic Caps
Finish: Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
External Coating: 3LPE / 3LPP/ FBE/ DFBE/ PP
Specification of Monel Alloy 400, K500 Pipes/Tubes
Monel Alloy 400 Seamless Tubes
Monel Alloy 400, K500 Pipes/Tubes
ASTM B165 Monel Alloy 400 Seamless Tubes, Monel Alloy K500 Seamless Tube, AS 400 Seamless Piping, Monel Alloy N05500 Seamless Tubes Supplier, Monel Alloy 2.4375 Seamless Tubes Exporter.
Alloy K500 Seamless Tubes
Monel Alloy 400, K500 Pipes/Tubes
ASTM B725 Monel Alloy 400 Seamless Tubes, Alloy K500 Seamless Tube, Monel Alloy 400 Seamless Tubing, Monel Alloy N04400 Seamless Tubes Supplier, Alloy 2.4360 Seamless Tubes Exporter.
Monel Alloy K500 Round Tubes
Monel Alloy 400, K500 Pipes/Tubes
ASTM B165 Monel Alloy K500 Seamless Tubes, Alloy 400 Seamless Tubing, Monel Alloy K500 Seamless Tubing, Alloy N05500 Seamless Tubing Supplier, Alloy 2.4375 Seamless Tubes Exporter.
Equivalent Grades of Monel Alloy 400, K500 Pipes/ Tubes
| STANDARD | UNS | WNR. | JIS | BS | GOST | AFNOR | EN |
| Monel 400 | N04400 | 2.4360 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
| Monel K500 | N05500 | 2.4375 | – | – | – | – | – |
Chemical Composition of Monel Alloy 400, K500 Pipes/ Tubes
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
Monel Alloy 400, K500 Pipes/ Tubes Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
