Monel Sheets, Plates and Coils Supplier
- Home
- Monel Sheets, Plates and Coils Supplier
Products
Dedicated Customer Teams & Agile Services
Our worldwide presence ensures the timeliness, cost efficiency compliance adherence required to ensure your production timelines are met.
Monel 400 Sheets, Monel Alloy HR Sheets and Plate Manufacturer, NW 4400, 5500 Sheets, Monel Cold Rolled Coils, Monel Alloy K500 Coils, UNS N04400, N05500 Plate, ASTM B127 Monel Alloy K500 Plates, Alloy 400 Coils, Monel Alloy 2.4360, 2.4375 Sheets, Monel Industrial Sheets, Plates and Coils Supplier in Pune India.
Om Steel is one of the prime manufacturers of Monel 400 / K500 Sheets, Plates and Coils that are being sourced by using high quality of raw material and makes sure to provide durability of highest quality of industry standard products. Monel 400 Sheets is a yielding Nickel-Copper alloy by means of resistance to an extensive range of corrosive state of affairs. Monel K500 Sheets is a Nickel Copper alloy which merges the exceptional corrosion resistance of Alloy 400 in the company of the additional benefits of better hardness and strength. Monel 400 Plates is most commonly applied in a variety of situations going from meekly oxidizing throughout nonaligned and to reasonably plummeting states. Meanwhile, these Monel 400/K500 Sheets, plates and coils can further be customized in terms of sizes and thicknesses as per specific requirements given by our esteemed clients.

Monel Alloy K500 Slit Coils, Alloy 400 Perforated Sheets, Monel K500 Shim Sheets, Alloy 400, K500 Strips, ASME SB127 K500 Monel Alloy Sheets Stockist, Monel 400 Chequered Plate, Monel Alloy 400, K500 Sheets, Plates, Coils Exporter in Pune India.
Specification of Monel 400, K500 Sheets, Plates, Coils
Specifications : ASTM B127 / ASME SB127
Dimensions : ASTM, ASME, and API
Size : 15NB to 150NB In
Thickness : from 2 to 40 mm
Prodction : Hot-Rolled (HR) / Cold-Rolled (CR)
Grade : Monel 400 / K500 UNS (N04400, N05500), DIN (2.4360, 2.4375)
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Available Types of Monel Alloy 400, K500 Sheets and Plates, Coils

Monel 400, K500 Sheets
Monel Alloy Sheets
Monel 400 Cold Rolled Sheets, Alloy K500 2B Finish Sheet, High Monel 400 No.1 Mirror Finish Sheets, Monel Alloy UNS N05500 CR Sheets, Alloy N04400 Hot Rolled Sheets, Monel Alloy 2.4375 Sheets Supplier, Alloy 2.4360 Sheets Exporter.

Monel 400, K500 Plates
Monel Alloy Plates
Monel 400 Cold Rolled Plates, Alloy K500 2B Finish Plate, High Monel 400 No.1 Mirror Finish Plates, Monel Alloy UNS N05500 CR Plates, Alloy N04400 Hot Rolled Plates, Monel Alloy 2.4375 Plates Supplier, Alloy 2.4360 Plates Exporter.

Monel 400, K500 Coils
Monel Alloy Coils
Monel 400 Cold Rolled Coils, Alloy K500 2B Finish Coil, High Monel 400 No.1 Mirror Finish Coils, Monel Alloy UNS N05500 CR Coils, Alloy N04400 Hot Rolled Coils, Monel Alloy 2.4375 Coils Supplier, Alloy 2.4360 Coils Exporter.
Equivalent Grades of Monel 400 / K500 Sheets, Plates and Coils
STANDARD | UNS | WNR. | JIS | BS | GOST | AFNOR | EN |
Monel 400 | N04400 | 2.4360 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
Monel K500 | N05500 | 2.4375 | – | – | – | – | – |
Chemical Composition of Monel 400, K500 Sheets and Plates, Coils
Grade | C | Mn | Si | S | Cu | Fe | Ni |
Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
Alloy 400 / K500 Sheets, Plate, Coils Mechanical Properties
Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
