Stainless steel forged fittings are an essential component of many industrial applications, and Omsteel is proud to offer a wide range of high-quality stainless steel forged fittings to meet your needs. Our products are made from top-quality materials and are designed to withstand the most demanding environments.
Our stainless steel forged fittings come in a variety of types, including elbows, tees, couplings, crosses, and unions. We offer a range of sizes and grades to ensure that you get the product that is right for your needs. Our fittings are forged using the latest technology and manufacturing techniques, ensuring that they meet the highest quality standards.
One of the standout features of our stainless steel forged fittings is their exceptional strength and durability. Our fittings are highly resistant to corrosion, oxidation, and heat, making them ideal for use in harsh environments. They are also easy to install and maintain, providing you with a cost-effective solution for your piping needs.
At Om Steel, we are committed to providing excellent customer service and support. Our team of experts is always on hand to answer any questions you may have and to provide you with the necessary guidance and support to ensure that you get the best possible product.
High Pressure Forged Fittings and ANSI Standards
The use of forged fittings is essential. These fittings are designed to withstand extreme conditions, including high temperatures and pressures, making them ideal for use in critical systems where safety and reliability are paramount. However, not all forged fittings are created equal. To ensure that these components meet the necessary standards for performance and safety, they must be manufactured according to strict guidelines set forth by organizations such as ANSI.
What Are High Pressure Forged Fittings?
High pressure forged fittings are components used in piping systems that are subjected to high pressures or temperatures. These fittings are made from solid blocks of metal that have been heated and then pounded into shape using a forging press. This process creates a dense, strong material with excellent mechanical properties.
The most common materials used for high pressure forged fittings include stainless steel, carbon steel, and alloy steel. Each material has its own unique properties that make it suitable for different applications. For example, stainless steel is often used in corrosive environments due to its resistance to rust and other forms of corrosion.
ASTM A Grade Stainless Steel Forged Fittings
ASTM A grade stainless steel forged fittings are a type of fitting that is commonly used in high-pressure piping systems. They are made from a specific type of stainless steel that has been forged into shape rather than cast.
One of the main benefits of using ASTM A grade stainless steel forged fittings is their strength and durability. Because they are made from high-quality materials and have been forged into shape, they can withstand high pressures without cracking or breaking.
Another benefit of using ASTM A grade stainless steel forged fittings is their resistance to corrosion. Stainless steel is naturally resistant to corrosion, which means that these fittings can last for years without rusting or corroding.
Stainless Steel Forged Fittings
Specification
| Forged Pipe Fittings Type | Socket Weld | Threaded |
|---|---|---|
| Pressure Class | 2000LBS, 3000LBS, 6000LBS, 9000LBS | 2000LBS,3000LBS, 6000LBS, 9000LBS |
| Fittings Form | 90° Elbow, 45° Elbow, Tee, Cross, Full Coupling, Half Coupling, Pipe Cap, Union, Reducer Insert, Boss, Branch Outlet, 90° Elbow Outlet, 45° Lateral Tee, Lateral Outlet, Branch Outlet Butt Weld, 90° Elbow Outlet Butt Weld, Lateral Outlet Butt Weld, Nipple Branch Outlet Butt Weld | 90° Elbow, 45° Elbow, Tee, Cross, Full Coupling, Half Coupling, Reducing Coupling, Pipe Cap, Hex Head Bushing, Hex Head Plug, Square Head Plug, Round Head Plug, Union, Hex Nipple, Street Elbow, Bull Plug, Boss, Swage Nipple, Pipe Nipple, Adapter, Union (Male x Female), Branch Outlet, 90° Elbow Outlet, 45° Lateral Tee, Lateral Outlet, Nipple Branch Outlet |
| Dimension Specifications | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8″~4″ (DN6~DN100) | 1/8″~4″ (DN6~DN100) |
| Thread | – | ISO, DIN, NPT, BSPT |
Stainless Steel Forged Fittings
Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| SS 304 | 1.4301 | S30400 |
| SS 304L | 1.4306 / 1.4307 | S30403 |
| SS 304H | 1.4301 | S30409 |
| SS 310 | 1.4841 | S31000 |
| SS 310S | 1.4845 | S31008 |
| SS 310H | – | S31009 |
| SS 316 | 1.4401 / 1.4436 | S31600 |
| SS 316L | 1.4404 / 1.4435 | S31603 |
| SS 316H | 1.4401 | S31609 |
| SS 316Ti | 1.4571 | S31635 |
| SS 317 | 1.4449 | S31700 |
| SS 317L | 1.4438 | S31703 |
| SS 321 | 1.4541 | S32100 |
| SS 321H | 1.4878 | S32109 |
| SS 347 | 1.4550 | S34700 |
| SS 347H | 1.4961 | S34709 |
| SS 904L | 1.4539 | N08904 |
Stainless Steel Forged Fittings
Stainless Steel
| Stainless Steel | ASTM A182 F-304/304H/304L/316/316H/316Ti, 309, 310, 317L, 321, 347, 904L |
|---|---|
| Duplex and Super-Duplex Steel | ASTM A 182-F51, F53, F55 |
| Nickel | ASTM B 564 N02200, N02201 |
| Inconel | ASTM B 564 N06600, N06601, N06617, ASTM B 564 N07718, ASTM B 564 N06625 |
| Incoloy | ASTM B 564 N08800, N08810, ASTM B 564 N08825, ASTM B 564 N08020 |
| Hastelloy | ASTM B 564 N10276, N06022, ASTM B 564 N10665, ASTM B 564 N06455 |
| Titanium-Commercially | ASTM B 861, 862, 338 Gr.1 R 56250(CP4) |
| Titanium-Pure | Gr.2 R 50400(CP3) Gr.3 R 50550(CP2) Gr.4 R 50700(CP1) Gr.7 R 52400 Gr.11 R 52250 |
| Titanium-Alloys | ASTM B 861, 862, 338 Gr.5 R 56400(6Al-4V) Gr.23 R 56401(6Al-4V-ELI) Gr.12 R 53400 |
| Cupro Nickel | ASTM B 171 C70600(90:10), ASTM B 171 C71500(70:30) |
| Monel | ASTM B 564 N04400 DIN N05500 |
| Carbon Steel | ASTM A 234 WPB IS 1239 PART II |
| Alloys Steel | ASTM A 234 WPB WP5, WP9, WP11, WP12, WP91 |
| Low Temp. CS | ASTM A-420 WPL6 |
| Other Service | Hot Dip Galvanizing, Sand Blasting |
