Titanium Sheet Sizes, Grades & Specifications: A Buyer’s Guide
Titanium sheet is specified by three things working together: grade, thickness, and surface condition. Get those right and the rest of the order — sizes, tolerances, certification — falls into place. This guide breaks down each so you can spec a sheet that fits your application the first time.
Common titanium sheet grades
Most titanium sheet sold for industrial use falls into a handful of grades. Grade 1 and Grade 2 are commercially pure (CP) titanium — Grade 2 is the workhorse, prized for its balance of strength, formability, and corrosion resistance. Grade 5 (Ti-6Al-4V) is an alpha-beta alloy that roughly doubles the strength of CP titanium, which is why it dominates aerospace and high-load parts. If you’re unsure which way to go, our breakdown of Grade 2 vs Grade 5 titanium walks through the trade-offs.
Standard thickness and size ranges
Titanium sheet is generally supplied from around 0.5 mm up to 6 mm (above this it’s classed as plate). Common sheet sizes run to 1000 x 2000 mm and 1250 x 2500 mm, though cut-to-size is widely available. When ordering, confirm:
- Thickness tolerance (cold-rolled sheet holds tighter tolerances than hot-rolled)
- Surface finish (pickled, descaled, or polished)
- Flatness and edge condition
Specifications to quote on every order
A clean titanium sheet spec includes the grade (e.g. ASTM B265 Grade 2), thickness, sheet size, surface condition, and any certification you need — typically a mill test certificate confirming chemistry and mechanical properties. For a fuller picture of how titanium behaves once it’s in service, see titanium sheet metal properties and uses.
FAQ
What’s the difference between titanium sheet and plate? Thickness. Sheet is generally up to ~6 mm; thicker material is plate.
Which grade is most common for sheet? Grade 2, because it forms and welds easily while resisting corrosion.
Need titanium sheet in a specific grade and size? Browse our titanium sheets or request a quote with your dimensions. For the full material overview, start with our titanium grades, sheets and bars guide.
FAQ's
Need Help?
We're Here for You!
Feel free to contact us any time. we will get back to you as soon as we can!
Ask Anything
Do you have any questions?
A: Carbon steel relies on carbon content alone for its properties. Alloy steel adds elements like chromium, nickel, molybdenum, and vanadium to achieve specific improvements — higher strength, better low-temperature toughness, creep resistance, or corrosion resistance — giving it a far broader performance range than carbon steel.
A: For ambient to 400°C service, ASTM A516 Grade 70 is the standard choice. For high-temperature refinery or power plant use (up to 600°C), ASTM A387 Grade 11 or 22 (chrome-moly) applies. For cryogenic service down to -196°C, 9% nickel steel (ASTM A553) is required.
A: Wear-resistant grades like AR400/AR500 are quenched to martensitic hardness of 370–500 HB — 3–4× harder than structural grades like A572-50. They resist abrasive wear in mining and construction equipment but have limited weldability and are not suitable as primary structural members.
A: CE (= C + Mn/6 + (Cr+Mo+V)/5 + (Ni+Cu)/15) predicts susceptibility to hydrogen-induced cold cracking during welding. Sheets with CE above ~0.40 require preheating to slow cooling and allow hydrogen diffusion, preventing weld cracking. Always develop a qualified WPS based on the specific CE value.
