1050, 1060, 1100, 6061, 6082 Aluminium Alloy Sheets
89 Reviews
Product Description:
Discover our versatile range of Aluminium Alloy Sheets, tailored to meet diverse industrial needs. The 1050, 1060, and 1100 sheets offer excellent corrosion resistance and workability, perfect for general sheet metal work where high mechanical strength is not required.
The 6061 and 6082 alloys provide a higher strength-to-weight ratio, with excellent machinability and toughness, ideal for structural applications such as bridges, cranes, and frames.
Available in various thicknesses and finishes, these sheets are designed to deliver performance and durability across a broad array of environments.
High-Quality Aluminium Sheets for Versatile Applications
The 1050, 1060, 1100, 6061, and 6082 aluminium alloy sheets are renowned for their exceptional mechanical properties, lightweight nature, and corrosion resistance. These sheets are designed to cater to diverse industrial applications, ranging from construction and transportation to aerospace and marine industries.
Product Overview
1050 Aluminium Alloy Sheet
- Characteristics: High purity (99.5% aluminium), excellent corrosion resistance, high ductility.
- Applications: Chemical and food industries, decorative panels, electrical conductors.
1060 Aluminium Alloy Sheet
- Characteristics: 99.6% aluminium content, high electrical conductivity, outstanding corrosion resistance.
- Applications: Transformer windings, kitchenware, signage.
1100 Aluminium Alloy Sheet
- Characteristics: Commercially pure aluminium, excellent thermal conductivity, corrosion resistance, and formability.
- Applications: Roofing, cladding, chemical storage tanks, heat exchangers.
6061 Aluminium Alloy Sheet
- Characteristics: Medium to high strength, excellent machinability, good corrosion resistance.
- Applications: Aerospace components, automotive parts, structural applications.
6082 Aluminium Alloy Sheet
- Characteristics: High strength, excellent corrosion resistance, and weldability.
- Applications: Marine structures, bridges, cranes, and heavy-duty structures.
Specifications
|
Grade |
Thickness Range |
Temper |
Standards |
Applications |
|
1050 |
0.2 mm to 200 mm |
H14, H24, O |
ASTM B209, EN 573 |
Chemical tanks, signage, conductors |
|
1060 |
0.3 mm to 150 mm |
H12, H14, H18 |
ASTM B209, EN 485 |
Transformers, utensils, solar reflectors |
|
1100 |
0.2 mm to 150 mm |
H14, H16, O |
ASTM B209, AMS 4001 |
Roofing, storage tanks, insulation |
|
6061 |
0.5 mm to 150 mm |
T4, T6 |
ASTM B209, AMS 4027 |
Aerospace, automotive, structural |
|
6082 |
1.0 mm to 200 mm |
T6, T651 |
ASTM B209, EN 485 |
Marine, transportation, construction |
Chemical Composition
|
Element |
1050 (%) |
1060 (%) |
1100 (%) |
6061 (%) |
6082 (%) |
|
Aluminium (Al) |
99.5 min |
99.6 min |
99.0 min |
Balance |
Balance |
|
Silicon (Si) |
0.25 max |
0.25 max |
0.45 max |
0.40-0.80 |
0.70-1.30 |
|
Iron (Fe) |
0.40 max |
0.35 max |
0.70 max |
0.70 max |
0.50 max |
|
Magnesium (Mg) |
– |
– |
– |
0.80-1.20 |
0.60-1.20 |
|
Manganese (Mn) |
0.05 max |
0.03 max |
0.05-0.20 |
0.15 max |
0.40-1.00 |
Mechanical Properties
|
Property |
1050 |
1060 |
1100 |
6061 |
6082 |
|
Tensile Strength (MPa) |
70-100 |
70-120 |
90-130 |
260-310 (T6) |
290-340 (T6) |
|
Yield Strength (MPa) |
30-50 |
30-50 |
40-70 |
240 (T6) |
260 (T6) |
|
Elongation (%) |
12-20 |
12-20 |
10-20 |
8-12 |
8-12 |
|
Hardness (HB) |
25-35 |
25-35 |
30-40 |
95-100 |
100-110 |
Key Features
- Corrosion Resistance: Ideal for environments exposed to moisture, chemicals, and saltwater.
- Lightweight Strength: High strength-to-weight ratio for ease of handling and transport.
- Versatile Applications: Suitable for a wide range of industries.
- Excellent Formability: Easy to machine, weld, and fabricate.
- Durable Finish: Resistant to wear and oxidation.
Why Choose Our Aluminium Alloy Sheets?
We offer a comprehensive range of 1050, 1060, 1100, 6061, and 6082 aluminium alloy sheets to meet the demands of various industries. With guaranteed quality, competitive pricing, and fast delivery, our products are designed to exceed your expectations.
Contact us now for expert advice, custom sizes, and bulk pricing for your aluminium sheet requirements!
